115V 1/8 HP Hot Water Circulator Pump Compatible with Grundfos UP15-29SU/LC 59896776 for House Heating System with Line Cord, 1-1/4" Union
$130.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by lmclinicxpress.com
We aim to show you accurate product information. Manufacturers, suppliers and others provide what you see here.
$130.00
Price when purchased online
Free shipping
Free 30-day returns
Sold and shipped by lmclinicxpress.com
Free 30-day returns Details
Product details
| Management number | 210144792 | Release Date | 2026/04/02 | List Price | $52.00 | Model Number | 210144792 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Technical Parameters: Supply Voltage: 115V; Rated Power: 1/8 HP; 1-1/4" Union; Port-to-port Length: 5.12" in Liquid;
- Replacement for UP15-29SU/LC and 59896776; Name: Non Submersible Circulation Pump
- Pressure & Temperature: Maximum operating pressure: 145 PSI ; Maximum ambient temperature: 104°F; Ambient max at 176°F liquid: 176°F; ; Standard: USA Threaded; Connection: 1 1/4" NPSM; Pressure stage: 10; Liquid temperature range: 36°F to 230°F
- Electrical Data: Number of poles: 2 Max; power input: 87W; Rated power - P2: 0.121 HP; Main frequency: 60 HZ; Rated voltage: 1 x 115V; Current in speed 3: 0.75A; Capacitor size - run: 10 µF/180V; Insulation class (IEC 85): F
- The pump is canned rotor type, pump and motor form an integral unit without shaft seal and with only two gaskets for sealing; The bearings are lubricated by the pumped liquid; The motor is a 1 phase motor. No additional motor protection is required.
- Buy With Confidence: We provide 12 months return policy.Any quality problems,we can replace new parts for you
| Color | Red |
|---|---|
| Voltage | 115 Volts |
| Brand Name | Dewinston |
| Manufacturer | Dewinston |
| Model Number | 59896776, UP15-29SU/LC |
| Power Source | Corded Electric |
| Material Type | Bronze |
| Product Style | Circulator |
| Included Components | Circulator Pump |
| Item Dimensions L x W x H | 6.6"L x 6.2"W x 6"H |
