47cm 49cm 52cm 54cm 56cm Road Bike Frameset 700C Carbon Quick Release Frame 100/142mm Disc Brake Carbon Fiber Tapered Fork(52cm)

Carbon Road Bike Framest – Lightweight, Stiff & High-PerformanceAerodynamic Design – Optimized tube shapes cut through wind for maximum efficiencyHidden internal routing: The frame with internal routing is simple and beautiful, with low wind resistance, and will not be affected by external forces on shifting and braking. The shifting cable is not easy to age.Frame name: Carbon fiber disc brake road frameFrame size: 47/49/52/54/56CMFrame material: T800Frame weight: 950g (52cm) unpainted, maximum difference ±20gHeadset: 1-1/8′1-1/2′upper 52mm lower 52mmBrake: disc brakeBottom bracket model: T47 threaded Φ46.8mm, L 86mmInstallation: suitable for DI2 and MechanicalSuitable wheels: 700C/28-30Opening: front 12*100mm; rear 12*142mmHandlebar weight: 370gFront fork weight: 375gFront fork diameter: 28.6mmSeat tube weight: 146gSeat tube length: 360mmProducts include: frame, front fork, seat tube, handlebar, headset, suspension center and wire accessoriesNotice:1. Please allow slight dimensional tolerances due to manual measurements, lighting in photography may cause color differences from real life.2. Please double check the size details in our list according to your actual situation to make sure you buy the right Bikes frame.

• Bike Frameset: 700C Road Bike Frameset, carbon Frame, carbonfork, Disc Brake Frame.
• Road cyclocross bike frames:47/49/52/54/56CM, recommended rider height 145-160cm/160-170cm/170-180cm/180-185cm/185cm above.
• Quick Release Frame: For seatpost, Seatpost Clamp, Head tube, 52x52mm headset, threaded bottom bracket, Quick Release F100mm R142mm QR, For 700Cx30 tires.
• Carbon frame: Carbon, tubing Process, High strength and light weight, good durability/riding comfort, and has good elastic properties for long riding.
• Package: Frame + fork + headset + seatpost + Seatpost Clamp
