Leviton Countdown Timer Switch for bathroom fan and household lights, 5-10-15-30 min, No Neutral Required, Single Pole, 15A, 1/2 HP/9.8A Fan/Motor, DT130-1LW, White
Product details
| Management number | 216535503 | Release Date | 2026/04/19 | List Price | $14.66 | Model Number | 216535503 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Leviton’s 30-Minute Countdown Timer Switch has 5-buttons with 5-minute, 10-minute, 15-minute and 30-minute preset time options and a manual off button. Works with existing wiring and can replace a standard switch for added convenience and energy savings. Easy DIY install, slim depth for easier fit in wall box, interchangeable line and load wires to help prevent miswiring, and a Green Flex Sleeve that connects to a ground wire, or to a neutral wire when the sleeve is removed. The appearance complements interiors and is compatible with other Decora devices. Easily change colors using DTKIT faceplates available in white, ivory, light almond, gray, black and brown. Ideal for bathroom exhaust fans, heat lamps, towel warmers and more. Do not use to control lights if it is the only light source in the area. Use with Decora Wallplate and Decora Plus Screwless Wallplate sold separately. Decora Countdown Timer Switch, single pole, 600W LED/CFL, 1800W Incandescent/Halogen, 1200VA Magnetic Low Voltage/Electronic Low Voltage/Fluorescent, ½ HP/9.8 Amp Fan/Motor, 15A Resistive – White
- CONVENIENT – replace your current wall switch with a countdown timer to automate fan/motor loads and lights. Four preset time buttons, press to turn on and automatically turns off when time expires
- EASY TO INSTALL – shallow design easily fits in the wallbox. 600W LED/CFL, 1800W Incandescent/Halogen, 1200VA MLV/ELV/Fluorescent, ½ HP/9.8 Amp Fan/Motor, 15A Resistive
- INNOVATIVE GREEN FLEX SLEEVE – wires to ground when no neutral wire is available or remove green sleeve and connect to a neutral wire if present in wallbox. A ground wire is required for installation
- DIY FRIENDLY – the device has two black wires that can be interchanged between line and load to help prevent miswiring
- ENERGY SAVING – ensure lights and fans are not left on unintentionally
- PRACTICAL – ideal to use for bathroom exhaust fans, heat lamps, towel warmers and more
- STYLISH – easily change the color using DTKIT faceplates available in white, ivory, light almond, gray, black and brown
| UPC | 078477264270 |
|---|---|
| Color | White |
| Model | DT130-1LW |
| Wattage | 1800 watts |
| Terminal | Screw |
| Brand Name | Leviton |
| Unit Count | 1.0 Count |
| Item Weight | 3.84 ounces |
| Switch Type | Push Button |
| Circuit Type | 1-way |
| Contact Type | Normally Open |
| Manufacturer | Leviton |
| Actuator Type | Push Button |
| Mounting Type | Wall Mount |
| Connector Type | Wire Leads |
| Control Method | Touch |
| Current Rating | 15 Amps |
| Item Type Name | Countdown Timer Switch for bathroom fan and household lights, 5-10-15-30 min, No Neutral Required, Single Pole, 15A, 1/2 HP/9.8A Fan/Motor, White |
| Operation Mode | Automatic |
| Controller Type | Timer Switch |
| Item Dimensions | 4.13 x 1.73 x 1.34 inches |
| Number of Items | 1 |
| Contact Material | Copper |
| Operating Voltage | 120 Volts |
| Specification Met | Csa, Fcc, Ic |
| Included Components | One DT130-1LW Leviton Decora 15 Amp, 30-Minute Countdown Timer Switch, White |
| Number of Positions | 4 |
| Connectivity Protocol | X-10 |
| International Protection Rating | IP00 |
