Pellethead Klauber 523900 Power Gear Slide Out RV Camper Motor for Lippert 383745, K01469C300, K01469-C300, 130-1235, K01265E300, 1510000006, 130-1164 & More, OEM Caliber

The Highest Quality Replacement RV, Camper, Motorhome Power Gear Slide-Out Motor for Klauber & Lippert. The motor is manufactured with 1/10 HP, 12 Volts DC, 13 AMPS, and a variation RPMs depending on the load. It’s designed with a intermittent duty reversible rotation as well as a 12 VDC electro-mechanical brake on rear of motor with manual release lever. This part is designed to meet all measurement specifications to ensure optimum system performance, reliability, and easy installation/maintenance for a safe system operation. It provides an exact drop-in replacement without the OEM price! Be sure to cross-reference your current specs – including gear base/bolt and housing patterns- to ensure a proper replacement fit. FEATURES 12 RPM (no load) 10 RPM – 400 in-lbs Torque 6 RPM – 850 in-lbs Torque Torque 850 in-lbs Holding Torque 500 in-lbs. Voltage 12 DC Enclosure TENV Equivalent to: KLAUBER 523900, Lippert 383745, K01469-B300, K01469B300, K01439E300, K01469C300, K01469-C300, 130-1235, 130-1204c, K01531A300, K01265E300, K01265F300, 1510000006, 130-1164, 130-1187, 13-1109, 130-1219, 520819, 522967, 523529, 521976, 13-1133, 13-1119, 523900, 523013, 523529, 524094, 524327, 524411, 523931, 524246, 520819, 522967, 523823, 1010000010, 523983, 522176 Check Lippert Specs For: 386322 Verify Lippert Bolt Pattern For: 521292, 521748, 523046, 523387, 368417, 522756, 524361, 523387, 524667 Check Lippert Bolt Pattern/Housing For: 523143, 386480, 382684, 368185, 523982, 523143S, 523766, K01265D300

• The Highest Quality Replacement RV, Camper, Motorhome Power Gear Slide-Out Motor for Klauber & Lippert Models.
• Specs: 1/10 HP, 12 Volts DC, 13 AMPS, 6-10 RPM Under Load, 12RPM No Load
• Equivalent to: KLAUBER 523900, Lippert 383745 K01469-B300, K01469B300 K01439E300, K01469C300, K01469-C300, 130-1235, 130-1204c, K01531A300, K01265E300, K01265F300, 1510000006, 130-1164, 130-1187, 13-1109, 130-1219, 520819, 522967, 523529, 521976, 13-1133, 13-1119, 523900, 523013, 523529, 524094, 524327, 524411, 523931, 524246, 520819, 522967, 523823 1010000010, 523983, 522176 & More!
• 2 Year Manufacturer Warranty
